profile Details

SPZ-C
Seismic Movement Capability Designed to accommodate horizontal and vertical movements caused by seismic activity. Durable Construction Made from high-strength aluminum alloy for exceptional durability and long service life. Streamlined Aesthetics The low-profile design, coupled with multiple gasket color options, seamlessly enhances aesthetics while preserving functionality. Versatile Weather Endurance Engineered with corrosion-resistant properties, this expansion joint […]
  • Product Model SPZ-C
  • Product Type Floor-Wall Expansion Joint Cover/Pan Seismic Profile
  • Material Aluminum Alloy 6063 T6, EPDM Rubber Gaskets
  • Finish Mill finish
#
Technical
Details
Technical
Drawings

Technical Details

Code Gap width
A (mm)
Visible width
B (mm)
Installation height
C (mm)
Installation Width
E (mm)
Thermal movement
(mm)
Siesmic movement
(mm)
Load Capacity
SPZ 100C 100 222 55 252 40mm (+20-20) 135mm (+80-55) Pedestrian
SPZ 150C 150 272 55 302 40mm (+20-20) 185mm (+80-105) Pedestrian
SPZ 200C 200 322 55 352 40mm (+20-20) 235mm (+80-155) Pedestrian
SPZ 250C 250 372 55 402 40mm (+20-20) 285mm (+80-205) Pedestrian
SPZ 300C 300 422 55 452 40mm (+20-20) 335mm (+80-255) Pedestrian
SPZ 400C 400 522 55 552 40mm (+20-20) 435mm (+80-355) Pedestrian

Technical Drawings

#

#
#

Feature and benefits

#

Seismic Movement Capability

Designed to accommodate horizontal and vertical movements caused by seismic activity.

#

Durable Construction

Made from high-strength aluminum alloy for exceptional durability and long service life.

#

Streamlined Aesthetics

The low-profile design, coupled with multiple gasket color options, seamlessly enhances aesthetics while
preserving functionality.

#

Versatile Weather Endurance

Engineered with corrosion-resistant properties, this expansion joint cover is well-suited for indoor and outdoor applications. For outdoor use, a water barrier must be incorporated to ensure optimal performance.

#

Easy Installation

Quick and hassle-free installation process with clear instructions provided.
